Microchip Technology MCP1826/MCP1826S Low Dropout Linear Regulators
Microchip MCP1826/MCP1826S Low Dropout (LDO) Linear Regulators are 1000mA linear regulators that provide high current and low output voltage. The MCP1826 is available in fixed or adjustable output voltage versions ranging from 0.8V to 5.0V. The MCP1826's 1000mA output current capability and low output voltage capability make it ideal for newer sub-1.8V output voltage LDO applications with high current requirements. The MCP1826S is a 3-pin fixed voltage version.CHARACTERISTIC
1000mA output current capability
Operating Input Voltage Range: 2.3V to 6.0V
Adjustable Output Voltage Range: 0.8V to 5.0V (MCP1826 Only)
Standard fixed output voltage
Other fixed output voltage options available upon request
Low Dropout Voltage: 250mV (Typical, 1000mA)
Typical Output Voltage Tolerance: 0.5%
Stable with 1.0µF Ceramic Output Capacitor
Fast Response to Load Transients
Low Supply Current: 120µA (Typical)
Low Shutdown Supply Current: 0.1µA (Typical) (MCP1826 Only)
Fixed Delay for Power Good Output (MCP1826 Only)
Short-circuit current limiting and thermal protection
Package options
APPLICATION
network interface card
Pocket PC
